Máy chủ SuperServer SYS-2049U-TR4
Key Features SuperServer SYS-2049U-TR4
• 48 DDR4 DIMM Slots, up to 6TB
• Up to 11 PCI-E 3.0 slots
• 4 Hot-Swap NVMe Bays support
via optional NVMe AOC
• Flexible Connectivity Options
Processor: 1 x Intel® Xeon® Processor SKL-SP 4110 8C/16T 2.1G 11M 9.6GT UPI
Memory: 16GB DDR4.
Network Controller: 4 Gigabit Ethernet ports via AOC-2UR66-i4G; Other options
Raid: RAID 0, 1, 5, 10
Storages: 24 Hot-swap 2.5″ SAS3/SATA3 drive bays supported via optional Add-on RAID
controller card; 4 Hybrid ports with NVMe support via extra AOC
Power: 1600W Redundant Power Supplies
Form Factor: Rackmount 2U
1. Quad socket P (LGA 3647) supports
Intel® Xeon® Scalable Processors, 3 UPI up to 10.4GT/s
2. Up to 6TB 3DS LRDIMM, up to DDR4-2666MHz; 48 DIMM slots
3. 5 PCI-E 3.0 x8 slots,
6 PCI-E 3.0 x16 slots
4. 4 GbE LAN ports via AOC-2UR66-i4G 1 dedicated IPMI LAN port
5. 24 Hot-swap 2.5″ SAS3/SATA3 drive bays supported via optional Add-on RAID
controller card; 4 Hybrid ports with NVMe support via extra AOC
6. Optional up to 2 Active Cooling GPUs
7. 4x 8cm heavy duty fans
8. 1600W Redundant Power Supplies Titanium Level (96%)
Product SKUs
SYS-2049U-TR4 SuperServer 2049U-TR4 (Black)
Motherboard
Super X11QPH+
Processor/Cache
CPU
Quad Socket P (LGA 3647)
Intel® Xeon® Scalable Processors,
3 UPI up to 10.4GT/s
Support CPU TDP 70-165W with IVR, 205W supported with optional kit
Cores Up to 28 Cores with Intel® HT Technology
